W25Q16V
11. ELECTRICAL CHARACTERISTICS
11.1 Absolute Maximum Ratings (1)
PARAMETERS
Supply Voltage
Voltage Applied to Any Pin
Transient Voltage on any Pin
Storage Temperature
Lead Temperature
SYMBOL
VCC
V IO
V IOT
T STG
T LEAD
CONDITIONS
Relative to Ground
<20nS Transient
Relative to Ground
RANGE
–0.6 to +4.0
–0.6 to VCC+0.4
–2.0V to VCC+2.0V
–65 to +150
See Note (2)
UNIT
V
V
V
° C
° C
Electrostatic Discharge Voltage
V ESD
Human Body
Model (3)
–2000 to +2000
V
Notes:
1. This device has been designed and tested for the specified operation ranges. Proper operation
outside of these levels is not guaranteed. Exposure to absolute maximum ratings may affect device
reliability. Exposure beyond absolute maximum ratings may cause permanent damage.
2. Compliant with JEDEC Standard J-STD-20C for small body Sn-Pb or Pb-free (Green) assembly and
the European directive on restrictions on hazardous substances (RoHS) 2002/95/EU.
3. JEDEC Std JESD22-A114A (C1=100pF, R1=1500 ohms, R2=500 ohms).
11.2 Operating Ranges
PARAMETER
Supply Voltage (1)
Ambient Temperature,
Operating
SYMBOL
VCC
T A
CONDITIONS
F R = 80MHz, f R = 50MHz
F R = 50MHz (for E3h
command)
Commerci al
Industrial
MIN
2.7
3.0
0
–40
SPEC
MAX
3.6
3.6
+70
+85
UNIT
V
°C
Note:
1. VCC voltage during Read can operate across the min and max range but should not exceed ±10%
of the programming (erase/write) voltage.
